  • Compact toilet partition CDF
  • Compact toilet partition CDF
  • Compact toilet partition CDF

Compact toilet partition CDF

  • 100% water resistant
  • Simple structure, light, use time up to 20 years.
  • Good heat resistance, resistant to specialized cleaning chemicals, very suitable for frequently humid environments such as toilets.
  • The surface is coated with Melamine, which helps to increase aesthetics, and is highly scratch resistant, dustproof, easy to clean and sanitize.
  • Cấu tạo thông số kĩ thuật

  • Bảng màu

  • Chứng chỉ CO-CQ

  • Bảo hành

  • Ưu điểm vượt trội của Jato

  • Báo giá sơ bộ

  • Cảnh báo

What is CDF toilet partition?

CDF full name is Compact Density Fiberboard, made from 100% wood fiber board with high temperature glue. Wood density is about 1400kg/m3.

CDF panels on the Vietnamese market today have a very diverse compression of 950psi, 1050psi, 1200psi, 1250psi,...,1400psi and are much less water resistant than compact hpl 1430psi.

Due to the appearance very similar to the first quality compact wall materials, if you are not a person working in the field of toilet partitions and knowledgeable about toilet wall materials, it is very difficult to distinguish the two types of materials. CDF - HPL.

Therefore, many units now use this type of compact density fiberboard to introduce to customers that it is a high-quality type 1 or type 2 sheet with water resistance of 90% - 95%. This is not true because the water resistance of CDF panels is very poor (the highest water resistance is about 80% - 1400psi compression), the ability to expand in water is high. But in fact, if you look at it with the naked eye, it is impossible to distinguish and see their water resistance.

Dimensions of CDF ngăn

CDF sheet on the market is manufactured in the same size as HPL sheet, mainly product in standard thickness 12mm, used to replace HPL sheet as needed.

The most popular sheet sizes today include:

       1220 x 1830 x 12mm

       1830 x 2440 x 12mm

The Vietnamese market, the most diverse is still the gray cdf sheet, standard size 1830 x 2440 x 12mm, compression 1400psi. In addition, there are still 18mm thickness cdf sheets for customers to use.

Cheap Compact toilet partition (Compact CDF) is composed of 3 main components: Compact CDF panels, installation accessories and shaping accessories.

Below is the structural model of the conventional Compact CDF toilet partition system:

Description table of sanitary partition materials CD:

STT

Part name Common materials

1

U roof ( Headrail)

Aluminum Anode, Inox

2

Hem khe

Aluminum Anode, Inox

3

Hinge ( Hinger)

Inox 201, Inox 304, Alloy, plastic

4

Holder ( Handle)

Inox 201, Inox 304, Alloy, plastic

5

Tripod ( Supporting leg)

Inox 201, Inox 304, Alloy, plastic

6

Lock up ( Lock)

Inox 201, Inox 304, Alloy, plastic

7

Hanger ( Hock)

Inox 201, Inox 304, Alloy, plastic

8

Quiz sheet ( Pilaster)

Compact HPL

9

Door ( Door)

Compact HPL

10

Room divider panels ( Partition)

Compact HPL

11

Ke corner ( Cap code)/ U Wall

Aluminum Anode, Inox

36213g

36213g

3629g

3629g

3615g

3615g

3612g

3612g

3611g

3611g

3610g

3610g

3507g

3507g

3167g

3167g

3092g

3092g

1029

1029

1028

1028

1027

1027

1026

1026

1013

1013

1006

1006

1004

1004

022-s

022-s

021-s

021-s

020-s

020-s

019-s

019-s

018-s

018-s

017-s

017-s

016-s

016-s

015-s

015-s

014-s

014-s

013-s

013-s

002-s

002-s

The warranty period is from the date of signing the acceptance report and handing over the project

During the warranty period, all equipment damaged due to manufacturer's fault will be repaired and replaced. Jato will not be responsible for warranty if the device loses its trademark, expires warranty, loses warranty card, is replaced by spare parts, or due to force majeure events such as natural disasters, fires, earthquakes... or other circumstances. The fault is not caused by the Manufacturer.

During the warranty period mentioned above, if the customer encounters a problem during use, Jato is responsible for repairing the warranty (The time Party B must be present at the equipment warranty site does not exceed 24 hours from the date of delivery). receive Party A's official notice in writing, fax or telephone). The content of the warranty covers the repair, repair, and replacement of defects caused by the manufacturer or caused by the installation. Jato bears all costs incurred related to the warranty of installed equipment for customers.

Warranty for all equipment up to 12 months

Owns exclusive plate edge processing technology

This technology helps to increase the gloss of the sheet edge and especially to increase the water resistance of the CDF sheet in a remarkable way. That is also the reason why Jato confidently increases the warranty period of Compact CDF toilet partition products up to 12 months.

Most competitive prices in the market

Why can Jato confidently affirm that we are the most competitive unit in the market for Compact toilet partition products?

+ Jato is a direct importer of plates and accessories, has a large inventory, so our input price is the best import price in the market.

+ Jato's technical team uses specialized software to extract materials to help optimize costs.

+ Vehicle fleet includes 3 trucks, maximum support for transportation fees.

+ Jato always applies the most competitive price policy to "long-term cooperation" with customers.

A team of engineers with more than 10 years of experience, is an expert in the field of sanitary partitions

+ Provide detailed and specific advice on solutions to help optimize installation costs and provide effective solutions to suit the needs of customers.

+ Follow up the construction, offer optimal solutions to the problems arising at the construction site

+ Design 2D, 3D BIM for all the works that we do

Skilled and professional technical team

+ Comply with the regulations at the construction site, regulations on labor protection.

+ Technical team with more than 10 members, meeting progress standards. Fast construction 100 m2/day.

+ Provide the optimal technical options for the actual arising on the construction.

Commitment "Do it right, do it right"

+ Follow the sample presented, using the compression titration plate signed with the customer. Say no to the phenomenon of "mixing plates", "mixing accessories" of poor quality, cheating customers.

The quotation for the construction of Compact CDF toilet partitions depends on many factors:

+ Compression of Compact CDF panels. The higher the compression, the better the water resistance and the higher the price. For Compact CDF toilet partitions, to ensure construction quality, Jato recommends customers to use panels with a compression of 1200psi or more.

+ Color of Compact CDF panels: Common gray or other solid colors (orange, blue, black) or wood grain color?

Gray construction price < Solid color construction price (Orange, blue, black...) < Wood grain color construction price

+ Dimensions of drawings: Design drawings according to standard or non-standard sizes?

Standard sizes will help optimize the number of panels used for the project, thereby optimizing costs and giving the best price to customers.

=>>> Refer to the article: Standard dimensions of Compact toilet partitions

+ Characteristics and installation conditions of each project

Is the installation on the first floor or a high-rise? If the building is high-rise, is there an elevator or elevator for transportation?

Is the installation concentrated in each area? Or is it sporadic layout at different points? What is the distance between the mounting points?

Quotation for construction of Compact CDF toilet partition (Preliminary)

STT

Product's name Plate color

Price ( VND) /m2

1

Compact CDF 1200psi toilet partition 12mm . thick Take note

500- 650k

2

Compact CDF 1200psi toilet partition 12mm . thick Solid color/ Wood grain

580- 700k

3

Compact CDF 1200psi toilet partition 12mm . thick Take note

600- 750k

4

Compact CDF 1400psi toilet partition 12mm . thick Solid color/ Wood grain

680- 900k

5

Compact CDF 1150psi toilet partition 18mm . thick Take note

750- 900k

6

Compact CDF 1400psi toilet partition 18mm . thick Take note

850- 950k

>>> The following quotation will only be a preliminary quote, to get the best quote for your CDF toilet partition project, please send detailed drawings of the work and contact the business of Jato for the most accurate quote.

Currently on the market, some CDF toilet partition construction units to compete unfairly have used some of the following tricks:

Using the plate is not the right compression signed with the customer

In order to reduce the current cost, many units have arbitrarily used plates with lower compression than the quoted compression and signed contracts with customers.

For example, a 1400psi sheet is reduced to a 1350psi plate, a 1200psi sheet is reduced to a 1150psi plate…

Because the texture of CDF panels is very difficult for customers to recognize if only using the naked eye.

Mixing poor quality accessories

Many units contract 304 stainless steel accessories but arbitrarily mix 201 stainless steel accessories, especially in parts that are less exposed to water such as handles, hinges, locks ...

How to check and monitor the quality of CDF toilet partition works?

This is really a very difficult question that Jato team received in the process of consulting CDF sanitary partition products. Because it is difficult to perceive the exact compression of CDF sheet products with the naked eye.

Usually people will use the standard weight table of the manufacturer to determine the compressibility of the CDF sheet.

Standard weight table for each CDF plate compression – DIYA factory

STT

Plate Type Standard weight

Dung sai

1

Plate CDF 1400psi- 12mm

67kg

+-2kg

2

Plate CDF 1200psi -12mm

59kg

+-2kg

3

Plate CDF 1050psi – 12mm

54kg

+-2kg

4

Plate CDF 1150psi- 18mm

77kg

+-2kg

5

Plate CDF 1400psi- 18mm

94kg

+-2kg

Even if you already know the weight standards of each type of compression, it is difficult to determine whether the contractor will do the 100% standard as signed or not? Because you cannot weigh 100% of the number of panels that the construction contractor brings to the construction site.

>>>> So the most effective solution is to find a contractor with a high reputation in the field of toilet partition construction and also have a long warranty, at least 12 months for the work to limit maximum risk.

As a contractor with more than 10 years of experience in the field of CDF sanitary partition construction. Jato is confident to be a reliable contractor. More than 1000+ projects done for more than 200 customers are proof of Jato's "credibility".
